Kanalai: 2kn. 1kps - 25kps
Kietųjų diskų skaičius: iki 1 x 3.5"
Palaikomos kameros: SD card Up to 128 GB, HD-CVI kameros, HD-CVI valdomos kameros (PTZ)
Video jungtys: VGA


Prekės kodas: 3680
Kaina su PVM: € 1155.43
Susisiekti dėl likučio
Pirkti



Aprašymas

Features:

• Support HDCVI/Analog Video input
• H.264 dual-stream video compression
• Support 2 ch 1080P+2 ch 720P realtime recording
• VGA/TV simultaneous video output
• Support 1 SATA HDD, 2 USB2.0
• Aviation connectors adopted
• Multiple monitoring: Web viewer, CMS(DSS) & DMSS

Technical Specifications:

System
• Main Processor Embedded microprocessor
• Operating System Embedded LINUX
Audio and Video
• Input 4 Channel (Don’t support audio in when connecting analog cameras)
• Two-way Talk 1 Channel Input, 1 Channel Output, RCA
Display
• Interface 1VGA, 2TV
• Resolution 1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
• Display Split 1/4
• Privacy Masking 4 rectangular zones (each camera) OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
• Video/Audio Compression H.264/G.711
• Resolution 2ch@1080P+2ch@720P(1~25/30fps)
• Bit Rate 48~8192Kb/s
• Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
• Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec,Post-record: 10~300 sec
Video Detection and Alarm
• Trigger Events Recording, PTZ, Tour, Alarm, Email, FTP, Buzzer & Screen tips
• Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
• Alarm input 7 channel
• Relay Output 2 channel
Playback and Backup
• Playback 1
• Search Mode Time/Date, Alarm, Motion Detection & Exact search (accurate to second)
Playback Function
• Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,
Digital zoom
• Backup Mode USB Device/Network
Storage
• Internal HDD 1 SATA Ports, Up to 2 TB capacity SD card 1 SD card, Up to 128 GB
Network
• Ethernet RJ-45 Port (10/100Mbps)
• Network Function TCP/IP, UDP, DHCP, DDNS, FTP, Email, Alarm Server
• Max. User Access 128 users
• Smart Phone iPhone, iPad, Android
Auxiliary Interface
• USB 2 Ports (1 rear), USB 2.0
• RS232 1 Port, for PC Communication and Keyboard
• RS485 1 Port, for PTZ Control
• Heater Optional
Electrical
• Power Supply DC 6V~36V
• Power Consumption <15W (Without HDD)
Environmental
• Operating Conditions -30°C (with heater)~ +60°C (+14°F ~ +131°F)
• Storage Conditions -30°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
• Construction
• Dimensions 178mm×220mm×50mm (7.0" x 8.7" x 2.0")
• Net Weight 2.1kg (4.6 lb) (without HDD)
Certifications
• CE FCC
• EN50155 ISO16750
