Kanalai: 8kn. 1kps - 25kps
Kietųjų diskų skaičius: iki 2 x 3.5"
Palaikomos kameros: SD card Up to 128 GB, Turbo HD, HD-CVI kameros, HD-CVI valdomos kameros (PTZ), IP kameros, Analoginės kameros, AHD
Video jungtys: HDMI


Prekės kodas: 3799
Kaina su PVM: € 1443.70
Susisiekti dėl likučio
Pirkti



Aprašymas

Features:

• Support HDCVI/Analog Video input
• H.264 dual-stream video compression
• Support 8 channel 1080P realtime recording
• VGA/TV simultaneous video output
• Support 2 SATA HDD, 2 USB2.0
• Aviation connectors adopted
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS

Technical Specifications:

System
• Main Processor Embedded microprocessor
• Operating System Embedded LINUX
Video
• Input 8 channel
Standard
• Analog NTSC(525Line), PAL(625Line)
• HDCVI 1080P HDCVI Camera
Audio
• Input 8 channel
• Output 1 channel
• Two-way Talk 1 channel Input, 1 channel Output
Display
• Interface 1VGA, 2TV
• Resolution 1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
• Display Split 1/4/8/9
• Privacy Masking 4 rectangular zones (each camera)
• OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
• Video/Audio
• Compression H.264 / G.711
• Record Rate Main Stream 8ch@1080P (1~25/30fps) Sub Stream D1(1~6/8fps)/CIF(1~25/30fps)
• Bit Rate 48~8192Kb/s
• Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
• Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
• Trigger Events Recording, PTZ, Tour, Alarm, Email, FTP, Buzzer & Screen tips
• Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
• Alarm Input 6 channel
• Pulse Input 1 channel
• Relay Output 2 channel
Playback & Backup
• Playback 1
• Search Mode Time/Date, Alarm, Motion Detection & Exact search (accurate to second)
• Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
• Backup Mode USB Device / Network
Network
• Ethernet RJ-45 port (10/100M)
• Wireless Network Built-in 3G/ 4G/Wi-Fi module
• GPS Built-in high accurate GPS module
• Network Functions TCP/IP, UDP, DHCP, DDNS, FTP, Email, Alarm Server
• Max. User Access 10 users
• Smart Phone iPhone, iPad, Android, Windows Phone
Storage
• Internal HDD 2 SATA ports
• Memory Slot 1 SD card
• Auxiliary Interface
• USB 2 ports , USB2.0
• RS232 1 port, For PC communication & Keyboard
• RS485 1 port, For PTZ control CAN Support
• Heater Optional
General
• Power Supply 6V~36V
• Power Consumption <15W(with HDD)
Working Environment
• -10°C ~+60°C / 10%~95%RH / 86~106kpa
• Dimension(W×D×H) 178mm×220mm×50mm
• Weight 2.1KG(with HDD)
• Vibration-proof 5Hz~200Hz: X / Y / Z each direction 5.5 hours 5Hz~5.5Hz: Vibration amplitude 12.7mm 5.5Hz~200Hz: 15m/s2
